wxpilot
A CLI for automating WeChat Mini Programs, built for AI Agents.
Lets an Agent drive the WeChat DevTools like a browser — page navigation, element interaction, state reading, network capture & mocking.
Table of Contents
- Features
- How It Works
- Prerequisites
- Installation
- Quick Start
- Core Concepts
- Command Reference
- Network Proxy & Mocking
- Low-Token Output Design
- Architecture
- Development
- AI Agent Integration
- MCP Integration
- dsh Integration
- Contributing
- License
Features
- Built for Agents: All command output is compact by default and uniformly truncated to 4000 characters, minimizing context consumption.
- Ref mechanism: After
view, interactive elements are auto-numbered%N; the Agent taps/types by number, with no need to maintain selectors. - Low-token lookup:
find <query>locates elements by text/class/placeholder/tag and returns%Ndirectly — no need to read the whole page. - Auto project detection: Omit the path and it auto-scans for
dist/project.config.jsonunder the current directory; prompts interactively when multiple candidates exist. - Built-in proxy capture:
--proxyspins up an HTTP/HTTPS MITM proxy in one command, supporting request mocking and body inspection. - JSON mode:
--jsonemits structured results for easy parsing by programs/Agents. - Managed daemon: The CLI auto-spawns a background daemon on first call, communicating over a Unix socket, and auto-exits after 30 min idle.
- Recommended Agent integration: Use the Skill + CLI workflow as the primary integration path; an optional MCP stdio adapter is available for MCP-based hosts.
How It Works
┌─────────┐ JSON-RPC ┌──────────┐ WebSocket ┌─────────────────────┐
│ wxpilot │ ────────────► │ daemon │ ────────────► │ WeChat DevTools │
│ (CLI) │ ◄──────────── │ (bg) │ ◄──────────── │ (automator + page) │
└─────────┘ Unix Socket └────┬─────┘ └─────────────────────┘
│
├── proxy HTTP/HTTPS MITM capture + mock
├── snapshot WXML → element tree + interaction detection
└── ref-store %N temporary refs + expiry validation
The CLI and daemon are decoupled: the CLI only parses arguments and formats output, while the daemon handles the actual automation, proxy, and state. They communicate over ~/.wxpilot/rust-daemon.sock.
Prerequisites
- macOS (currently only macOS binaries are provided; Linux/Windows are not yet supported)
- WeChat DevTools installed and running
- Building from source requires the Rust stable toolchain (
rustup show)
Installation
One-line install (macOS)
curl -fsSL https://raw.githubusercontent.com/wuliLiuyue/wxpilot/main/install.sh | bash
Install a specific version:
curl -fsSL https://raw.githubusercontent.com/wuliLiuyue/wxpilot/main/install.sh | bash -s -- --version v0.1.0
Custom install directories:
curl -fsSL https://raw.githubusercontent.com/wuliLiuyue/wxpilot/main/install.sh | bash -s -- \
--install-dir ~/.local/bin --daemon-dir ~/.wxpilot/bin
After install:
wxpilot→~/.local/bin/wxpilotwxp-daemon→~/.wxpilot/bin/wxp-daemon
If ~/.local/bin is not in PATH, append it as prompted:
echo 'export PATH="$HOME/.local/bin:$PATH"' >> ~/.zshrc
Build from source
cd rust
cargo build -p wxp-cli --bin wxpilot
cargo build -p wxp-daemon --bin wxp-daemon
./target/debug/wxpilot --version
packages/webis the website source, unrelated to the CLI — you can ignore it when building from source.
Quick Start
# 1. Start automation (auto-detect dist/project.config.json, or pass a path explicitly)
wxpilot start
wxpilot start /path/to/miniprogram
wxpilot start /path/to/miniprogram --proxy # capture: auto-spawns a proxy on 8899
wxpilot start /path/to/miniprogram --appid wxYourAppID
# 2. Connect
wxpilot connect
# 3. View the page to get interactive element refs %N
wxpilot view
wxpilot find submit # low-token lookup, returns matching %N directly
# 4. Interact
wxpilot tap %1
wxpilot type %2 "13800138000"
wxpilot goto /pages/order/index
# 5. Refs become invalid after navigation — re-fetch
wxpilot view
# 6. Read state / assert / screenshot
wxpilot state cart.total # read only the sub-field you need
wxpilot assert %3 "Submitted successfully"
wxpilot shot /tmp/result.png
Core Concepts
Ref mechanism
After running wxpilot view or wxpilot find, interactive elements on the page are assigned temporary numbers %N (starting from %1).
- Numbers are regenerated on each
view/find. - After
goto/back/reload, numbers are invalidated — re-runview. - Using an expired ref errors with:
ref_expired: %N.
Interactive node detection (dual signal): the outerWxml() snapshot from DevTools does not preserve event attributes like bindtap, so two signals are used:
data-*attributes — preserved in the snapshot, used as a proxy signal for bindtap (~80% coverage).- Source-file fingerprints — read the
.wxmlsources, extracttag:sorted-classesfingerprints of nodes that have bindtap, and recover nodes missed by thedata-*heuristic.
Project path auto-detection
The projectPath argument of wxpilot start is optional:
- When omitted, scans up to 2 levels of subdirectories under CWD for
distdirectories containingproject.config.json. - Single candidate: used automatically.
- Multiple candidates: interactive selection.
- No candidate: error, prompting you to pass it manually.
Command Reference
Connection management
wxpilot start # auto-detect dist/project.config.json
wxpilot start <projectPath> # start automation (cli auto, wait for ready)
wxpilot start <projectPath> --appid <id> # specify when appid is a placeholder
wxpilot start <projectPath> --cli-path <path> # path to the DevTools CLI
wxpilot start <projectPath> --auto-port 9421 # automation port (default 9420)
wxpilot start <projectPath> --proxy # auto-start a 127.0.0.1:8899 proxy
wxpilot start <projectPath> --proxy --https # HTTPS MITM capture (install CA first)
wxpilot connect # connect (using the endpoint recorded by start)
wxpilot connect --ws <wsEndpoint> # specify a ws endpoint directly
wxpilot disconnect
wxpilot status
Navigation
wxpilot goto <route> # e.g. /pages/order/index
wxpilot back
wxpilot reload
View
wxpilot view # compact interactive summary (compact, depth=5, limit=50)
wxpilot view --full # full tree (incl. non-interactive nodes, depth=20)
wxpilot view --depth <n>
wxpilot view --limit <n>
wxpilot find <query> # match text/class/placeholder/tag, interactive nodes only by default
wxpilot find <query> --all # include non-interactive nodes
wxpilot find <query> --limit <n>
wxpilot wait %N [--timeout 5000]
Interaction
wxpilot tap %N
wxpilot type %N <text>
wxpilot scroll %N <up|down>
Read
wxpilot read %N # read element text
wxpilot assert %N <expected> # assert text (exit code 1 on mismatch)
wxpilot state # top-level key summary (type + size)
wxpilot state [path] # a specific sub-path, e.g. cart.items
wxpilot state --full # full page data
wxpilot shot [path] # screenshot, save file and return the path
wxpilot shot [path] --base64 # screenshot with a base64 payload
Network proxy
wxpilot net start [--port 8899] [--https] # start the proxy standalone (--https decrypts HTTPS)
wxpilot net stop
wxpilot net log [--filter <url>] [--limit 20] # summary, without bodies
wxpilot net log [--filter <url>] --with-body # incl. request/response bodies (truncated to 2000 chars)
wxpilot net mock <url> <jsonFile>
wxpilot net unmock <url>
wxpilot net clear
wxpilot net install-ca # install the CA into the keychain (first HTTPS use)
Execution
wxpilot run <js> # run JS in the page VM (no Node.js API access)
wxpilot wx <method> [args...] # invoke a wx API
Daemon
wxpilot daemon stop
wxpilot daemon restart
Global options
--timeout <ms> default 10000ms
--verbose verbose logging
--json JSON-formatted output
Network Proxy & Mocking
For capture, prefer wxpilot start <projectPath> --proxy [--https], which ensures the proxy is up within the same session.
HTTP mode
wxpilot start <projectPath> --proxy
wxpilot connect
wxpilot net clear
wxpilot goto /pages/xxx/index
sleep 3
wxpilot net log --filter api.example.com
HTTPS MITM mode (install the certificate the first time)
# One-time setup
wxpilot net start --https # generate the CA certificate
wxpilot net install-ca # install it into the system keychain
# Fully quit and restart WeChat DevTools (a restart is required)
# DevTools: Settings → Proxy → Manual → 127.0.0.1:8899
# Each capture session
wxpilot start <projectPath> --proxy --https
wxpilot connect
wxpilot net log --filter api.example.com --with-body
Mock
wxpilot net mock https://api.example.com/order ./mock-order.json
mock-order.json format:
{
"status": 200,
"body": { "code": 0, "data": { "items": [] } }
}
Notes
- Once you set a proxy in DevTools, the tool's own internal requests also go through the proxy; when the proxy isn't running, the page may report
TypeError: Failed to fetch. - After
net install-ca, you must fully restart DevTools for it to take effect. - In HTTP mode, HTTPS requests are transparently tunneled (not recorded); to record HTTPS traffic you must use
--https. - Port fallback: default is
9420. Ifconnectsucceeds butstatusis abnormal, runwxpilot daemon stop, then restart with--auto-port 9421, trying 9422/9423 next.
Low-Token Output Design
The default output of each command is optimized for AI context consumption:
| Command | Default behavior | Full output |
|---|---|---|
view |
Compact interactive summary (compact, depth=5, limit=50) | --full |
find |
Minimal summary of matched elements (interactive only, limit=10) | --all |
state |
Top-level key summary (type + size) | --full or a specific path |
shot |
Save a file, return the path | --base64 |
net log |
Summary fields, limit=20, no body | --with-body |
All command output is uniformly truncated to 4000 characters; when truncated, a [truncated, originalLength=X] hint is appended.
Architecture
| Module | Responsibility |
|---|---|
wxp-cli |
Argument parsing, daemon detection/spawn, RPC calls, output formatting |
wxp-daemon |
JSON-RPC server, runtime state, automator, proxy and storage |
wxp-rpc + wxp-common |
RPC protocol and shared constants |
wxp-snapshot + wxp-ref-store |
WXML → element tree, interaction detection, %N ref storage |
wxp-proxy + wxp-store |
HTTP/HTTPS proxy, network log storage |
Default runtime files:
~/.wxpilot/rust-daemon.sock— daemon communication socket~/.wxpilot/rust-daemon.pid— daemon PID lock (ensures a single instance)
Development
# Build
cd rust && cargo build --workspace
# Test
make rust-test # equivalent to cd rust && cargo test --workspace
# Local build & install loop (macOS arm64 / x86_64)
make local-build # artifacts in dist/local/<target>/
make local-install # install to ~/.local/bin and ~/.wxpilot/bin
make local-install-all # build + install in one go
# Release packaging (generates GitHub Releases archives)
make public-release-package VERSION=v0.1.0
# → dist/public-release/v0.1.0/wxpilot-darwin-{arm64,x64}.tar.gz + checksums
Upload the three files under dist/public-release/<version>/ (two tar.gz archives + wxpilot-checksums.txt) to GitHub Releases, and users can install via the one-line script.
AI Agent Integration
The repo ships skills/wxpilot/SKILL.md, a complete usage guide for AI Agents, covering:
- Agent decision logic for project path detection
- A typical Agent workflow (start → find → interact → assert → screenshot)
- JSON-mode output format
- Port-fallback troubleshooting
- Low-token usage guidelines
Reference this file directly as a skill description when integrating with an Agent.
For new Agent integrations, prefer Skill + CLI: the Skill provides the workflow guidance and the CLI remains the stable execution interface. This path has the smallest integration surface and keeps the full CLI behavior available.
MCP Integration
MCP is supported as an optional integration layer for hosts that already manage tools through MCP.
Build the adapter from the repository root:
pnpm install
pnpm --filter @wxpilot/mcp build
Example MCP client configuration:
{
"mcpServers": {
"wxpilot": {
"command": "node",
"args": [
"/absolute/path/to/wxpilot/packages/mcp/dist/index.js"
],
"env": {
"WXPILOT_BIN": "/absolute/path/to/wxpilot/rust/target/debug/wxpilot",
"WXPILOT_CWD": "/absolute/path/to/miniprogram"
}
}
}
}
The adapter exposes one tool, wxpilot_execute, and supports the existing connection, navigation, interaction, state, screenshot, JavaScript, wx API, and network operations. start requires an explicit projectPath; daemon stop and restart are intentionally not exposed. See packages/mcp/README.md and packages/mcp/README.zh-CN.md for the complete configuration and development guide.
dsh Integration
A native DeepSeek Harness (dsh) bundle plugin exposes wxpilot as one model-facing wxpilot tool: it drives the Rust CLI directly through the ctx.subprocess seam, with typed schemas, a canonical JSON result, and a terminal card.
pnpm dsh:build
dsh plugin --profile demo add ./packages/dsh
The plugin shares its argv whitelist with the MCP adapter through @wxpilot/shared; JS-evaluating operations (run, wx) stay hidden unless enableJsEval: true is configured. See packages/dsh/README.md and packages/dsh/README.zh-CN.md for loading, configuration, and development.
Contributing
Issues and Pull Requests are welcome.
- The main implementation language is Rust; by default, modify
rust/crates/wxp-cliandrust/crates/wxp-daemon. - Make sure
make rust-testpasses before submitting. - There is no CI configured — please run tests locally before committing.
License
This project is open-sourced under the GNU Affero General Public License v3.0 or later (AGPL-3.0-or-later) © wuliLiuyue.
- ✅ Personal study, research, internal use, modification, and redistribution are all allowed (you must keep the copyright notice and likewise open-source under AGPL-3.0-or-later).
- ✅ Commercial use is also allowed, but derivative works and services provided over a network must be open-sourced under AGPL-3.0-or-later (i.e. "copyleft").
- ❌ You may not distribute this project or its derivatives in closed-source/proprietary form, or provide them as closed-source services.
- 💼 To embed this project into a closed-source/proprietary commercial product or service, please contact the author for a commercial license.
Third-party dependencies (such as tokio, clap, etc.) remain under their respective MIT/Apache-2.0 licenses.
相关推荐Related
- deepseek-ai/deepseek-harness DeepSeek Harness: Everything is a Plugin.
- deepseek-ai/deepseek-harness DeepSeek Harness (dsh) — 由 DeepSeek AI 开发的开源 agent harness（智能体框架）。一切皆插件：核心 + 插件 + 技能 = 可热插拔的 AI 编程工作台。DeepSeek Harness: …
-
ruvnet/ruflo
🌊 The original agent meta-harness. Deploy intelligent multi-player swarms, coordinate autonomous workflows, and build c…
-
amruthpillai/reactive-resume
A one-of-a-kind resume builder that keeps your privacy in mind. Completely secure, customizable, portable, open-source a…
-
volcengine/OpenViking
Self-evolving Context Database for AI Agents. Unify Agent Memory, Knowledge RAG and Skills.
-
Molunerfinn/PicGo
:rocket: The Ultimate Image Uploader for Efficient Creators. Supports Obsidian, Typora, VS Code etc. and 60+ image hosti…
-
titanwings/colleague-skill
将冰冷的离别化为温暖的 Skill，欢迎加入数字生命1.0！Transforming cold farewells into warm skills? It's giving rebirth era. Welcome to Digital …
-
nocobase/nocobase
NocoBase is an open-source AI + no-code platform for building business systems fast. Instead of generating everything fr…
