Xizhi1024/deepseek-harness-dsh-for-vscode 预览 preview

Xizhi1024/deepseek-harness-dsh-for-vscode

Embeds the local DeepSeek Harness (DSH) web UI in the VS Code auxiliary sidebar (right rail, alongside Copilot Chat). By default, every VS Code window starts and owns one dsh web child with the current workspace as cwd, then renders it in a compact full-screen iframe.

catalog 简介 / catalog descriptioncatalog description:DeepSeek Harness(dsh) for VS Code

项目介绍Project Overview

DSH for VS Code 把本地 DeepSeek Harness Web UI 嵌入右侧栏,每个窗口自动启动并管理一个 dsh web 子进程,工作区为 cwd。默认共享官方 DSH 主目录(~/.dsh),可切换独立隔离模式。支持选区右键以 Markdown 链接加入对话草稿、剪贴板与编辑器互通、主题跟随 VS Code、工作区热切换而不重启。需 VS Code ≥ 1.06、全局安装 @deepseek-ai/dsh;0.9.2–0.9.3 版本需运行时 ≥ 0.1.0-rc.7,否则因未知 --no-open 参数启动失败。

DSH for VS Code embeds the local DeepSeek Harness web UI in the auxiliary sidebar, with each window owning one managed dsh web child using the workspace as cwd. It shares the official DSH home by default (switchable to isolated), bridges clipboard, file-open, links, and theme to VS Code, and queues selection ranges as compact Markdown links. Use it when coding alongside a DSH session. Caveat: builds 0.9.2–0.9.3 require DSH runtime ≥ 0.1.0-rc.7; older runtimes fail with unknown option '--no-open'.

或使用命令行安装(适合开发者)Or use CLI install (for developers)

命令行安装CLI Install

dsh plugin --profile web add github:Xizhi1024/deepseek-harness-dsh-for-vscode

Xizhi1024/deepseek-harness-dsh-for-vscode 加入你的 DSH 配置(web profile)即可启用。

READMEREADME

DeepSeek Harness(dsh) for VS Code

English · 简体中文

Embeds the local DeepSeek Harness (DSH) web UI in the VS Code auxiliary sidebar (right rail, alongside Copilot Chat). By default, every VS Code window starts and owns one dsh web child with the current workspace as cwd, then renders it in a compact full-screen iframe.

🚨 KNOWN CRITICAL ISSUE (0.9.2–0.9.3): managed startup fails on DSH runtime < 0.1.0-rc.7

[!WARNING] Since 0.9.2 the extension passes --no-open on every managed dsh web launch, but that flag only exists in @deepseek-ai/dsh ≥ 0.1.0-rc.7. On older runtimes (e.g. 0.1.0-rc.6) the CLI rejects the unknown option and exits immediately — every managed spawn dies with error: unknown option '--no-open', the sidebar can never start, and the extension keeps retrying across candidate ports (3080/3081/3082). The error is visible in the spawn logs under the extension's globalStorage (dsh-server-*.log).

Fix / workaround: upgrade the runtime — npm i -g @deepseek-ai/dsh@0.1.1-rc.1 (anything ≥ 0.1.0-rc.7 works) — or install an extension build ≤ 0.9.1. The next release gates the flag on the runtime version.

VS CODE INTERACTION GUARANTEE (0.9.0)

In an extension-owned DSH session, model-output Copy and native ⌘C/⌘X/⌘V (Ctrl+C/X/V) inside the embedded page use the VS Code clipboard—including selections inside the chat composer—, Read … files—including absolute paths from shared older sessions outside the current workspace—open in the exact owning VS Code window, and HTTP/HTTPS links open in VS Code Simple Browser. The embedded page follows the VS Code color theme (light/dark) instead of the OS. Markdown files no longer fall through to Windows file associations such as Typora. Right-click the editor body to add either the whole file (Add File to DSH Thread, no selection required) or the current selection (Add to DSH Thread); both append only a compact Markdown file/link to the active DSH draft—never the selected source text. Clicking the rendered link reopens that approved file/selection in the owning VS Code window. Nothing is ever auto-sent.

Selection-link example

Select one or more code ranges, right-click Add to DSH Thread, and the DSH draft receives compact file-and-line Markdown links instead of pasted source code. The screenshot shows two selections queued in the same draft.

Add selected VS Code ranges to a DSH conversation as compact links

🚨 IMPORTANT: ISOLATED MODE CAN MAKE ALL EXISTING MODULES APPEAR TO DISAPPEAR

[!IMPORTANT] The default is dsh.home.mode: shared (since 0.6.0): the extension directly uses the official DSH home (DSH_HOME, otherwise ~/.dsh). Existing modules, skills, providers, credentials, presets, and sessions are therefore shared with standalone DSH.

Set dsh.home.mode to isolated only when this VS Code extension needs a completely separate module configuration. Isolated mode uses the extension's private globalStorage/.dsh, initially containing only the official web profile. Switching modes can therefore make every module appear to disappear, but nothing is deleted—the data remains in the other DSH home. The extension never copies or merges the two homes.

On the first upgrade from 0.4.x, a non-empty legacy isolated home is preserved automatically unless you already selected a mode. Use DSH: Diagnose to see the effective mode and path, then switch to shared explicitly when ready.

Starting dsh web with VS Code when dsh.autoStart=true is intentional. Runtime binaries and DSH user data are independent: both the local official npm package and a manifest/SHA-256-verified managed runtime use the selected shared/isolated home.

Requirements

Item Requirement
VS Code ≥ 1.106, desktop only
DSH (default auto-start) npm install -g @deepseek-ai/dsh; the extension detects the official package
Node.js auto-detected; set dsh.local.nodePath for non-standard locations
DSH configuration no pre-creation needed; shared mode creates/reuses official ~/.dsh, isolated mode creates the extension-private home

Install

  • Dev: open this repo → F5Run Extension
  • Verify: npm cinpm run check:w0npm run test:extension-host
  • Secret scan: npm run test:secrets scans the source/docs that would enter the VSIX (never node_modules, .git, or .vscode-test) and exits 1 on hardcoded bridge tokens, Authorization: Bearer credentials, API keys, private keys, or password literals; example/test fixtures are released with an explicit // allow-secret-scan comment.
  • Package: npm i -g @vscode/vsce && vsce package --no-dependenciescode --install-extension deepseek-harness-dsh-for-vscode-0.9.2.vsix

Usage

  • Ctrl+Alt+B opens the auxiliary sidebar → DeepSeek Harness (DSH) tab
  • Opt-in Ctrl+L (Cmd+L on macOS): with dsh.keybindings.ctrlL enabled, pressing it in the editor adds the active selection to the DSH conversation
  • Opt-in Ctrl+I (Cmd+I on macOS): with dsh.features.ctrl-i enabled, run Edit with DSH Files (Ctrl+I); pick 1–8 workspace files in the QuickPick and the multi-file context block is sent to the DSH conversation. No default keybinding is contributed.
  • Opt-in Ctrl+K (Cmd+K on macOS): with dsh.features.ctrl-k enabled, select code and run Edit with DSH (Ctrl+K); type an instruction and the selection+instruction draft is sent to the DSH conversation. No default keybinding is contributed — add one yourself:
    { "key": "ctrl+k", "command": "dsh.ctrlKEdit", "when": "editorTextFocus && editorHasSelection" }

    (macOS: use "key": "cmd+k")
  • Commands (command palette): Open DSH in Browser · New Session · Switch Session · Open Session History · Restart DSH Server · Restart DSH Server Cleanly · Stop DSH Server · Focus DSH Sidebar · Add File to DSH Thread · Add Folder to DSH Thread · Add to DSH Thread · Add Active File to DSH Context · Add Active Selection to DSH Context · Add Problems to DSH Context · Capabilities and Integrations · Diagnose · Clean Up Orphan DSH Servers · Set up DSH · New DSH Instance · DSH Changes · Set DSH FIM API Key
  • With dsh.autoStart on, the server is started at VS Code startup even if the sidebar is never opened
  • Extra surfaces: run DSH: New DSH Instance (or enable the sidebar title-bar entry with dsh.multiInstance.entry) to open another DSH panel in the editor area. All surfaces share the window's single DSH process; each panel gets its own DSH session (dsh_session), and closing a panel releases that session only
  • Model routing (L2, off by default): set dsh.lm.route to fixed or dynamic (with dsh.features.lm-route) and DSH models appear in the VS Code language-model chat picker as vendor dsh, served through bridge-token-authenticated /api/lm routes — never through Copilot quota
  • MCP consumption (L2, off by default): with dsh.features.mcp-consume enabled, DSH can use the VS Code-side MCP servers configured in the DSH profile through vscode/mcp/* bridge methods; every server/tool call passes the consent gate (DSH: Refresh MCP Servers / DSH: Forget MCP Consent)
  • Changes review (L2, off by default): with dsh.features.changes-review enabled, workspace edits pushed by DSH appear in the DSH Changes tree with open-diff / accept / undo actions and approval prompts before any file is touched

Restart DSH Server Cleanly disables every non-core (non-@deepseek-ai/*, non-embed) plugin in the active profile via vscode-clean.overlay.yml before restarting. When startup fails with HEALTH_TIMEOUT or SPAWN_EXITED_EARLY, the status page offers a Restart-Clean entry; in clean mode it shows a banner with Restart-normal, which restarts with the normal embed overlay. A startup that exits early while a --patch overlay is in effect automatically retries exactly once without the patch (recorded in Diagnose).

First-run setup (onboarding)

On the first activation the extension asks “DSH is ready — set it up?” with three choices: Set up opens a multi-step wizard, Not now asks again on the next activation, and Never stops asking (until the command is run). The wizard walks through the profile (default web, validated against ^[A-Za-z0-9._-]{1,64}$; a change takes effect after reloading the window), auto-start, close policy, an informational watchdog / roadmap step (display-only; opt-in L2 features such as multi-instance, Tab completion, MCP, and model routing are listed as switches you enable later in Settings), the implemented DSH feature switches, and a summary to confirm. Every accepted step writes its dsh.* setting immediately (global scope), so skipping a step keeps its current value. All copy is bilingual through the vscode.l10n bundle. Re-run the wizard at any time with the Set up DSH command, and change individual values later in Settings (dsh.*).

Session navigation

New Session / Switch Session / Open Session History use DSH's local session API. Switch Session shows a QuickPick with each root session's title, workspace path, update time, and running state; selecting one reloads the iframe with the dsh_session query parameter so the DSH web UI opens that session. Open Session History is the same picker under the dsh.features.chat-participant gate, and exits with a warning when no server or no session is available. The extension does not keep a second session tree — the DSH server remains the source of truth. New Session creates a session for the current workspace root and, when one already exists, reuses a blank session for the same cwd instead of creating a duplicate.

Chat participant (@dsh)

With dsh.features.chat-participant enabled (L2, default off), the extension contributes the @dsh participant to the VS Code chat view. Type @dsh followed by your prompt: the participant resolves the current workspace DSH session, enqueues the prompt (session.prompt, mode queue), and streams the DSH session's text deltas back into the chat response. Follow-ups offer up to five recent root sessions for one-click continuation.

D9 boundary: the participant never reads request.model and never consumes the vscode.lm / Copilot quota — it talks only to the DSH-owned session API on the local loopback server.

Tab completion (FIM POC)

With dsh.features.tab-completion enabled (L2, default off), the extension registers an inline completion provider for file-scheme documents and injects a per-window DSH_FIM_BRIDGE_TOKEN into the managed DSH child so the DSH-side vscode-fim plugin's /api/fim endpoint only answers this window.

This is a POC-grade feature. If it does not meet the D13 quality bar it will be removed as a whole rather than shipped in a half-broken state.

  • Model selection: the DSH-side vscode-fim plugin owns fimApi / fimBaseUrl / fimModel; the extension side only selects the model through dsh.fim.model (machine scope).
  • API key: set it with the Set DSH FIM API Key command; it is stored in VS Code secretStorage (dsh.fim.apiKey), never in dsh.* configuration.
  • Default off: zero registration and zero spawn-env injection while the feature is disabled.

Editor context (explicit attachment)

Right-click the editor body and choose Add File to DSH Thread (no selection required) or, with a selection, Add to DSH Thread. Both focus the DSH sidebar and append only a Markdown link such as [app.js](https://github.com/Xizhi1024/deepseek-harness-dsh-for-vscode/blob/HEAD/…) / [app.js:5-8](https://github.com/Xizhi1024/deepseek-harness-dsh-for-vscode/blob/HEAD/…); no source text is pasted into the draft. After the message is rendered, clicking the link reopens the approved file range in the owning VS Code window. Existing draft text is preserved, and the extension does not send automatically.

Right-click a folder in the Explorer and choose Add Folder to DSH Thread. The draft receives only a compact folder link; DSH reads back a bounded listing of relative paths (depth ≤ 2, at most 500 entries, skipping node_modules, .git, and hidden entries) through the same attachment channel — never the folder's file contents. Clicking the rendered link reveals the folder in the Explorer (revealInExplorer), available on every platform.

Add File to DSH Thread and Add Folder to DSH Thread are the only commands that may attach a trusted file:// document/folder located outside the open workspace folders (for example a file opened via File > Open File…, or a trusted folder). That explicit-user-action approval only applies to the command itself and to the produced attachment link; the versioned bridge's open, openDiff, and wire-supplied diagnostics requests remain workspace-only, and Add Active File / Selection / Problems keep their implicit-attachment workspace gate.

The extension never sends editor content implicitly. The active file, selection, folder listing, and Problems stay out of DSH until you run one of the Add … commands; the resulting attachment is the only thing the vscode_editor tool can read back through the versioned bridge.

  • File, selection, folder, and Problems attachments are window-memory only and are cleared when the workspace root changes.
  • Attachments over 1 MiB (UTF-8) are rejected instead of silently truncated; diagnostics are capped at 1000 items and 2000 chars per message; folder listings are capped at 2 levels / 500 entries.
  • Bridge open/openDiff/wire-supplied diagnostics only accept file URIs inside an open, trusted workspace folder — the bridge exposes no arbitrary command, URI, or file read.
  • DSH receives vscode/contextChanged notifications carrying revision and attachment ids only, never content. CH1 v2 adds metadata-only selectionChanged / activeEditorChanged / diagnosticsChanged notifications, validated against V2_NOTIFICATION_SCHEMA at the host boundary.

Exports API

When dsh.features.exports is enabled, the extension's activate() function returns a frozen programmatic face (version: "1") with three methods:

Method Signature Description
ask ask(prompt, opts?) → Promise<{accepted: true, sessionId}> Enqueue a prompt into the current workspace session. prompt is a non-empty string of at most 100000 characters; opts.sessionId (defaults to the current workspace session), opts.mode ("queue" or "steer"), opts.signal (AbortSignal).
listSessions listSessions(opts?) → Promise<Array<object>> List DSH sessions through the session API; opts.signal is forwarded.
addContext addContext(uri, range?) → Promise<{id, kind, uri}> Attach one file:// URI (string or vscode.Uri) to the current context. A trailing / routes to a folder attachment; range is {start:{line,character}, end:{line,character}} for file attachments.

Stable error codes (DshExportError.code): DSH_EXPORT_DISABLED, DSH_EXPORT_NO_SERVER, DSH_EXPORT_INVALID_PROMPT, DSH_EXPORT_INVALID_URI, DSH_EXPORT_OUTSIDE_WORKSPACE, DSH_EXPORT_TOO_LARGE, DSH_EXPORT_TOO_MANY_FILES.

v1 boundaries:

  • No streaming: ask returns {accepted: true, sessionId} only; there is no SSE/text-delta streaming surface.
  • addContext is bounded: one URI per call; editor-context budgets still apply (files over 1 MiB are rejected instead of truncated).
  • L2 default off: the face exists with dsh.features.exports off so third parties can depend on the stable shape, but every method call throws DSH_EXPORT_DISABLED until the setting is enabled.
  • Breaking changes require a major version: the face is frozen at version: "1"; method removal/signature changes must ship as a new major.
  • Third-party enablement: consumers set dsh.features.exports to true (machine scope) in settings, then read the returned face from activate().

Capabilities & diagnostics

Capabilities and Integrations focuses the DSH sidebar and opens the capability center in the DSH web UI. The extension ships a small controlled provider catalog (src/capabilityCatalog.js) and a provider detector (src/providerDetector.js) that reports install/enable state for four framework candidates only:

  • Remote development: ms-vscode-remote.remote-wsl, ms-vscode-remote.remote-ssh
  • GitHub: GitHub.vscode-pull-request-github
  • Browser: browser-provider-placeholder (framework placeholder until the W5 browser provider is selected and verified)

The extension never installs third-party providers. Every third-party provider is manual-assist in this round; none is marked integrated because the stable-interface audit (G3) is still open. vscode/extensions/openDetails only opens the catalog-controlled VS Code extension details page or an official https:// documentation page — there is no install code path.

Diagnose reads the dsh.* configuration, server state, bridge state, catalog revision, and provider detection results, then shows a single summary message. Diagnostics are also mirrored to the DSH OutputChannel (VS Code → Output → DSH) — the last link of the failure-degradation chain — including feature failures, startup errors, self-heal events and orphan-sweep events.

Workspace & bridge capabilities (0.6–0.9)

  • Plugin catalog (src/catalog/*, src/detection/*, src/diagnose/*): a schema-validated catalog contract describes DSH plugin categories/entries, and the L3 probe detects installed plugins in the selected DSH home. Diagnose includes the plugin summary.
  • Workspace registry (src/context/workspaceBinding.js, src/ch2/workspaceClient.js): the sidebar binds VS Code workspace roots through DSH's workspace.list/create API. Switching the active workspace root rebinds the DSH session through the registry — the owned child process is not killed or restarted. Owned servers auto-create the workspace record; reused servers ask for consent.
  • CH1 v2 (src/protocol/ch1.js, src/ch1/notifier.js): the versioned bridge negotiates protocol v1/v2 and adds metadata-only selectionChanged / activeEditorChanged / diagnosticsChanged notifications, coalesced by a 150 ms notifier and validated against V2_NOTIFICATION_SCHEMA.
  • Command shell (src/commands/shell.js, src/commands/addFileToThread.js): a capability-router gate for commands; dsh.addFileToThread is the first command wired through it.

Provider state is refreshed through vscode.extensions.onDidChange, which emits vscode/providerStatesChanged notifications on the versioned bridge. Detection re-reads vscode.extensions on every call and never caches state across workspaces.

VS Code bridge capabilities & roadmap

The versioned bridge (versionedBridgeServer + CH1 protocol, v1→v3 negotiated) is the channel DSH uses to reach the VS Code window. Always-on methods stay read/open-only and are guarded by workspace trust plus per-window loopback tokens; every capability that touches terminals, UI surfaces, editor buffers or cross-extension calls ships off by default behind an explicit dsh.bridge.* / dsh.features.* consent switch.

Exposed to DSH (always on)

Type Exposed methods / notifications
Editor read vscode/editor/getContext
Open file vscode/editor/open
Open diff vscode/editor/openDiff
Diagnostics vscode/workspace/getDiagnostics
Extension / provider vscode/extensions/getProviderStates · vscode/extensions/openDetails · vscode/extensions/list
Workspace search vscode/workspace/findFiles
Notifications (v1) vscode/contextChanged · vscode/providerStatesChanged · vscode/workspaceChanged
Notifications (v2) + vscode/editor/selectionChanged · vscode/editor/activeEditorChanged · vscode/diagnosticsChanged

Exposed to DSH behind consent switches (v3, default off)

Switch Capability family
dsh.bridge.terminal vscode/terminal/create · vscode/terminal/sendText · vscode/terminal/read — integrated terminals created/sent/read through the bridge (max 8 concurrent, ring-buffer readback)
dsh.bridge.ui vscode/window/showMessage · vscode/confirm/ask · vscode/progress/* · vscode/statusbar/update · vscode/output/append — user-visible VS Code surfaces
dsh.bridge.editorRead vscode/editor/getState · vscode/editor/read — read the active editor's unsaved buffer
dsh.features.changes-review vscode/changes/push — DSH-proposed workspace edits reviewed in the DSH Changes tree (open-diff / accept / undo, approval-gated)
dsh.features.mcp-consume vscode/mcp/listServers · vscode/mcp/listTools · vscode/mcp/callTool — consent-gated MCP tool calls
dsh.features.call-export vscode/extensions/callExport — call other extensions' exports faces behind the consent gate with a call journal
Tasks & debug vscode/tasks/list · vscode/tasks/run · vscode/debug/start · vscode/debug/stop · vscode/debug/getStack — launch-config debug sessions plus tasks.json execution
Git read vscode/git/getStatus · vscode/git/getDiff — read-only Git state via the built-in Git extension API

Not exposed yet

  • File editing: applyEdits / direct workspace file mutation
  • Debug breakpoints / step control (sessions and stack readback only)
  • Git writes: stage, commit, apply diff

Roadmap to Cursor / Claude Code-style experience

The v3 bridge now covers much of the original roadmap — terminals, tasks, debug start/stop/stack, Git status/diff readback, workspace search, confirm/progress/status-bar/output UI surfaces, and the changes-review approval layer. What remains:

  1. Write-side editor methodsvscode/editor/applyEdit and direct workspace file mutation, with per-edit approval and rollback.
  2. Debug depth — breakpoints and step control (sessions and stack readback already work).
  3. Git writes — stage / commit / apply-diff, each behind explicit confirmation.
  4. Agent-loop UX polish — streaming terminal output into the conversation, diagnostics/test feedback loops, and in-editor accept/reject UI for model suggestions.

Current status: the always-on surface stays read/open-only; every capability that can execute or mutate anything ships behind an explicit consent switch (see the table above).

Configuration

Key Default Description
dsh.port 3080 Port to probe/start the DSH web server on
dsh.host 127.0.0.1 Fixed loopback bind required by the current DSH Web profile
dsh.autoStart true At VS Code startup, launch the official DSH with the selected home and web profile; reuse the configured endpoint if runtime resolution fails (false = reuse only)
dsh.home.mode shared shared uses the official DSH home; isolated uses extension-private globalStorage/.dsh and a separate module configuration
dsh.home.path (empty) Machine-scoped absolute override for shared mode; empty follows DSH_HOME, then ~/.dsh
dsh.profile web Window-scoped DSH profile directory under the selected home; must match ^[A-Za-z0-9._-]{1,64}$
dsh.closePolicy onVscodeExit When to stop the extension-owned server (see below)
dsh.local.packageRoot (empty) Machine-scoped optional absolute official @deepseek-ai/dsh package root; empty auto-detects the global npm installation
dsh.local.nodePath (empty) Machine-scoped optional absolute Node.js executable path; empty auto-detects it
dsh.runtime.manifestUrl (empty) Machine-scoped optional HTTPS runtime release manifest; empty uses the local official npm DSH, non-empty opts into manifest/SHA-256-verified managed-runtime provisioning
dsh.runtime.version (empty) Optional managed-runtime version pin; only applies with a manifest URL
dsh.features.clipboard-bridge true Embedded copy/paste bridge between the DSH iframe and the VS Code clipboard (L1 feature, off = DSH copy buttons write to the webview clipboard)
dsh.features.thread-attachment true Add the active file/selection/problems to the DSH conversation (L1 feature, off = Add to Thread commands are not registered)
dsh.features.editor-links true Open DSH Read… and draft attachment links in this VS Code window (L1 feature, off = text document bridge is not started)
dsh.features.statusbar-basic true Basic DSH status indicator in the status bar (L1 feature, off = the L0 $(error) fallback still surfaces on failure)
dsh.features.theme-follow true Follow the VS Code active color theme (dark/light) in the embedded DSH iframe (L1 feature, off = no dsh_theme URL param and no theme listener)
dsh.features.changes-review false Review workspace edits proposed by DSH: approval prompts, the dsh.changes tree view, and the vscode/changes/push bridge handler (L2 feature)
dsh.features.ctrl-k false Enable the Edit with DSH (Ctrl+K) command; no default keybinding is contributed (L2 feature)
dsh.features.ctrl-i false Enable the Edit with DSH Files (Ctrl+I) command that picks 1–8 workspace files and sends them as a multi-file context block (L2 feature)
dsh.features.lm-route false Expose DSH models to the VS Code language-model chat picker as vendor dsh (L2 feature)
dsh.lm.route off DSH model routing mode: off = never register the dsh chat provider; fixed = fetch /api/lm/models once and cache; dynamic = refresh the model list on every picker open
dsh.features.mcp-consume false Let DSH consume VS Code MCP servers through the bridge (vscode/mcp/listServers/listTools/callTool) (L2 feature)
dsh.features.exports false Enable the programmatic exports API returned by the extension activate() face (ask/listSessions/addContext) (L2 feature; disabled calls throw DSH_EXPORT_DISABLED)
dsh.features.call-export false Let DSH call other extensions' exports faces through vscode/extensions/callExport behind the consent gate, with a call journal (L2 feature, machine scope)
dsh.features.chat-participant false Enable the @dsh chat participant in the VS Code chat view; consumes DSH sessions only, never the vscode.lm/Copilot quota (L2 feature)
dsh.features.tab-completion false Enable the DSH FIM tab-completion provider for file documents (L2 feature; POC-grade)
dsh.fim.model (empty) Machine-scoped DSH-side FIM model name used for tab completion; the upstream API key and base URL are configured in the DSH-side vscode-fim plugin
dsh.keybindings.ctrlL false Enable the Ctrl+L (Cmd+L on macOS) keybinding that adds the active editor selection to the DSH conversation (off by default)

| dsh.multiInstance.entry | false | Show the new-instance entry in the DSH sidebar title bar (off by default) | | dsh.bridge.terminal | false | Let DSH use VS Code terminals through the runtime bridge (create/send/read, max 8) | | dsh.bridge.editorRead | false | Let DSH read the active editor's unsaved buffer through the bridge | | dsh.bridge.ui | false | Let DSH show user-visible VS Code surfaces through the bridge (window messages, progress notifications, status bar, output channel, confirm/ask prompts) |

dsh.closePolicy values:

Value Behavior
onVscodeExit Stop the owned server only when VS Code exits (default)
onViewClose Also stop the owned server when the sidebar view is closed
never Never stop automatically — use the Stop DSH Server command; the child watchdog is disabled, and the process keeps running after VS Code exits (a later activation's orphan sweep, or Clean Up Orphan DSH Servers, reclaims it)

A reused (non-owned) instance is never stopped by any policy or command.

Compatibility

  • VS Code ≥ 1.106 (secondarySidebar); explicit activationEvents; extensionKind: [workspace]
  • Windows / macOS / Linux
  • Each managed DSH child receives an authenticated loopback bridge URL/token; supported DSH builds POST configuration paths back to the owning extension host, which opens them through vscode.window.showTextDocument in that exact window. DSH_TEXT_EDITOR=vscode remains only as an older-DSH CLI fallback; reused external servers keep their own editor policy
  • The iframe receives dsh_embed=vscode, which supported DSH builds use to hide their internal sidebar, details column, and resize handles; Open in Browser keeps the normal full layout
  • Managed children receive a generated --patch overlay at DSH_HOME/.integrations/vscode-sidebar/vscode-embed.overlay.yml. It disables plugins known to duplicate embedded chrome (better-sidebar, ui-dsh-aionui-panel) without editing DSH sources, profiles, or the user's cordis.patch.yml
  • Default autoStart accepts only a local npm package whose identity is @deepseek-ai/dsh, resolving the real package, entrypoint, and Node executable to absolute paths; it never executes an identity-unknown dsh shim from PATH. With an explicit manifest URL, the managed runtime still verifies its pointer, manifest, and payload SHA-256. Either path tries to reuse a DSH already serving the configured endpoint before showing an error
  • Cleanup: taskkill /T /F tree-kill (Windows — force-terminated, not a graceful stop); detached spawn + kill(-pid) process-group SIGTERM (POSIX)
  • Untrusted / virtual workspaces unsupported (spawns local processes, touches workspace files) — declared via capabilities
  • Container/view IDs dsh-sidebar / dsh.webview are persistent contracts — never change them in a release (resets the user's sidebar layout)
  • UI language follows VS Code (zh/en): manifest via package.nls.*.json, runtime via vscode.l10n (l10n/bundle.l10n.*.json)
  • Release verification is local: npm run check:w0 plus npm run test:extension-host; the repository intentionally carries no GitHub Actions workflow.

Security & trust model

The extension runs two bridges with two different trust scopes, and the boundary is deliberate:

  • Versioned CH1 bridge (src/versionedBridgeServer.js, authenticated by a per-window random token in DSH_VSCODE_BRIDGE_* env): open, openDiff, and wire-supplied diagnostics accept only file:// URIs inside open, trusted workspace folders, plus attachments the user explicitly approved. This is the model-driven (vscode_editor) surface.
  • Text document bridge (src/textDocumentBridge.js, separate per-process token in DSH_VSCODE_OPEN_TOKEN): intentionally opens any absolute local path in the owning VS Code window after a trusted-workspace check, so Read … links from older shared-home sessions whose cwd lies outside the current workspace keep working. The token is only injected into this extension's owned DSH child, but DSH is an agent harness: anything a model inside that child decides to open is equivalent to the user opening it. It is an open-in-editor path only — it reads no file content back to DSH and cannot execute commands — yet it can still steal window focus (showTextDocument(preserveFocus: false)).
  • dsh.addFileToThread is a middle ground: an explicit user command may attach a trusted workspace-outside file:// document; the resulting attachment link reopens through the approved-attachment path only.

If you use shared-home DSH sessions with a model you do not fully trust, keep workspace trust on and treat the embedded DSH like an agent with editor-open capability — not like a sandboxed webview.

Startup error codes

Startup failures are classified centrally in src/startupErrors.js. Each code carries retryable, a localized template, and a diagnoseHint; dsh.diagnose prints the healthy code table. Unknown codes fall back to the original error text.

Code Retryable Template
AUTOSTART_DISABLED no DSH is not running and dsh.autoStart is disabled
CONFIG_HOST_UNSUPPORTED no Unsupported dsh.host "{host}"; this extension requires {expected}
CONFIG_PORT_INVALID no Invalid dsh.port "{port}"; expected an integer from 1 to 65535
CONFIG_PACKAGE_ROOT_INVALID no Invalid dsh.local.packageRoot: {path}
CONFIG_NODE_PATH_INVALID no Invalid dsh.local.nodePath: {path}
CONFIG_HOME_PATH_INVALID no Invalid DSH home path: {path}
CONFIG_PROFILE_INVALID no Invalid dsh.profile: {profile}
RUNTIME_NOT_INSTALLED yes Official DSH is not installed. …
RUNTIME_NODE_MISSING yes Node.js was not found …
NO_FREE_PORT yes No free port found within {limit} ports starting from {start}
SPAWN_ERROR yes Failed to start dsh: {error}
SPAWN_EXITED_EARLY yes DSH process exited early (code={code}, signal={signal})
HEALTH_TIMEOUT yes DSH service did not become ready within {seconds}s; process terminated (pid={pid})
BRIDGE_INIT_TIMEOUT yes VS Code bridge initialization timed out

Clean-restart handling for HEALTH_TIMEOUT / SPAWN_EXITED_EARLY is part of the B batch and is not implemented in A batch.

Known limitations

  • Real browser provider not integrated: the capability catalog only lists browser-provider-placeholder; provider selection and verification are deferred to W5.
  • Extension Host smoke version: the smoke test currently runs against VS Code 1.106 by default.
  • Spawn output goes to a per-spawn log, not the OutputChannel: the DSH child's stdout/stderr is captured in <globalStorage>/dsh-server-<port>-<pid>.log (truncated on each spawn) when the instance registry is writable; the DSH OutputChannel carries extension-side diagnostics (feature failures, startup errors, self-heal, orphan sweeps), not the child's raw stdout/stderr.
  • Orphan DSH processes are reclaimed automatically: registry entries carry the owning window (vscodePid + windowId). On every activation the extension tree-kills entries whose owner extension-host is confirmed dead (living owners are never touched), and a watchdog (default on, off under closePolicy: never) lets a VS Code-managed DSH child self-terminate once its heartbeat file goes stale and its parent process is gone (dual condition, plus window-ownership and PID-reuse guards). Clean Up Orphan DSH Servers remains for user-driven review of surviving/legacy instances.
  • Startup failures are centrally classified: startup error codes live in src/startupErrors.js with retryable / template / diagnoseHint; the Retry button is hidden for configuration-only classes and stays available for runtime/spawn/health classes. Clean restart (Restart-Clean) is a separate B-batch item.
  • Some DSH copy buttons may still fail: the bridge only replaces navigator.clipboard.writeText; a DSH UI fallback that uses document.execCommand('copy') writes to the webview clipboard instead of the VS Code clipboard and belongs to the DSH UI side. Model-output Copy through the standard clipboard API works.

Implementation

Repository layout: src/ (extension host), runtime-integration/dsh-vscode-integration/ (the DSH-side dual-half plugin the extension syncs into the DSH home), test/ (unit + extension-host suites), scripts/ (lint / packaging / secret-scan gates), media/, l10n/. Internal implementation notes, QA findings and batch planning live under docs/dev/ and never enter the published VSIX; user-facing issue history is in KNOWN_ISSUES.md and CHANGELOG.md.

File Responsibility
src/extension.js extension-host assembly and DSH connection orchestration
src/editorContext.js explicit editor attachments, open/openDiff, diagnostics, workspace URI gate
src/threadAttachment.js acknowledged Webview bridge for appending an editor selection to the active DSH draft
src/capabilityCatalog.js controlled W4 provider catalog, URI whitelist, catalog revision
src/providerDetector.js provider install/enable/health detection, bridge handlers, diagnostic snapshot
src/versionedBridgeServer.js versioned loopback bridge (editor, diagnostics, extensions)
src/textDocumentBridge.js per-window token loopback bridge for opening DSH-owned text documents
src/bridgeWorkspace.js bridge workspace identity and trust classification
src/embedOverlay.js generated --patch overlay for the managed DSH child
src/dshHome.js shared/isolated home resolution, 0.4.x migration guard, runtime/home binding
src/lifecycle.js serialized lifecycle queue and shutdown gate
src/localRuntimeResolver.js discovers/verifies the local official npm DSH and prepares the selected DSH home
src/managedRuntimeLaunch.js verified managed-runtime launch spec, profile/path normalization, --patch passthrough
src/runtimeResolver.js managed runtime resolution with current/last-good pointer verification
src/runtimeProvisioner.js release-manifest parse, artifact selection, resolve-or-provision orchestration
src/runtimeArtifact.js runtime manifest validation, SHA-256 verification, runtime directory verification
src/runtimeArchive.js verified tar.gz extraction for the managed runtime
src/runtimeDownloader.js HTTPS runtime download with redirect limit and SHA-256 verification
src/runtimeInstaller.js current/last-good runtime install, pointer switching, atomic writes
src/serverManager.js probe / reuse / start / registry / cleanup
src/sessionNavigation.js DSH session list/create API client and QuickPick mapping
src/vscodeFacade.js injectable VS Code API surface
src/webviewHtml.js iframe + status pages
src/webviewMessages.js fixed Webview message routing
src/protocol/webview.js webview bridge constants/validators (request-id rule shared by shell, host, client)
src/protocol/ch1.js CH1 v1/v2 method/notification contract and V2_NOTIFICATION_SCHEMA enforcement
src/ch1/notifier.js metadata notification coalescer with v2 schema validation
src/ch2/workspaceClient.js DSH workspace registry API client
src/context/workspaceBinding.js workspace registry binding state machine
src/commands/shell.js capability-router command shell
src/commands/addFileToThread.js dsh.addFileToThread command body
src/catalog/catalogSchema.js plugin catalog schema validation
src/catalog/pluginCatalog.js installed-plugin catalog snapshot
src/detection/pluginDetector.js L3 installed-plugin probe
src/detection/profileProbe.js DSH profile/entry probing
src/detection/probeTypes.js probe result/state contracts
src/diagnose/pluginSummary.js diagnose plugin summary
src/adapters/contract.js capability adapter contract
src/workspaceContext.js settings, workspace root, registry path
src/types.js contract constants (port, boot marker, view ID)

Key behaviors:

  • Probe GET / for the __DSH_BOOT__ marker (3s timeout, 3 retries — a busy DSH is never misjudged as absent)
  • Before every autoStart spawn, connectNow resolves the selected shared/isolated home independently, re-discovers and verifies the local official @deepseek-ai/dsh, then launches --profile web; the SHA-256-verified managed-runtime path is used only when dsh.runtime.manifestUrl is explicitly configured and is rebound to the same selected home
  • Default autoStart mode does not adopt another window's process: occupied ports are scanned forward (up to 50) and each extension host owns its child; only a local-runtime resolution failure triggers reuse of an existing configured endpoint
  • cwd = current workspace (multi-root: active editor's folder; none: inherit parent cwd, no home fallback)
  • Remote (WSL / Remote-SSH): vscode.env.asExternalUri port forwarding
  • Browser commands use the same externalized URL as the iframe, including remote sessions and connection-error fallback pages
  • Only the iframe URL gains the dsh_embed=vscode compact-layout marker; browser URLs remain unmodified
  • Workspace switch: rebind the DSH session through the workspace registry without killing or restarting the owned child (PID stays the same)
  • onStartupFinished activation: with dsh.autoStart on, the server starts at VS Code startup (null-safe when no webview is open)
  • With the default onVscodeExit policy, extension deactivation cancels pending startup, waits for the serialized lifecycle queue, and tree-kills any child that appeared; closing one VS Code window does not affect another window's child
  • Lifecycle transitions (connect / stop / workspace rebind / config reconcile) run through one serialized queue, so a dispose arriving during connect cannot kill a process a rebind just started
  • dsh.stopServer and the close policy stop only owned processes; a reused external instance is never killed
  • Registry pruning only removes dead entries and never kills a live process; onVscodeExit stops an owned child during extension-host shutdown, while never intentionally lets it survive until explicitly stopped
  • Editor bridge requests reject non-file URIs, URIs outside workspace.getWorkspaceFolder, and untrusted workspaces; remote URIs are never converted to local paths

FAQ

  • "DeepSeek official API" key is read-only in DSH settings? DSH deliberately treats DEEPSEEK_API_KEY supplied by the launching environment as read-only (writes would be silently shadowed). Fix: unset it in the shell that starts dsh web (or VS Code) and restart — the key already stored in ~/.dsh/.credentials.yaml takes over and the field becomes editable.

Troubleshooting

"Official DSH is not installed" while the global package IS installed (2026-08-17)

Symptom: the sidebar reports Official DSH is not installed … (status page shows http://127.0.0.1:3080) while npm ls -g lists @deepseek-ai/dsh.

Cause: Settings Sync carried the Mac's machine-specific values into the Windows user settings:

"dsh.local.packageRoot": "/Users/zhengduojie/.nvm/versions/node/v24.18.1/lib/node_modules/@deepseek-ai/dsh",
"dsh.local.nodePath": "/Users/zhengduojie/.nvm/versions/node/v24.18.1/bin/node",

On win32 these POSIX paths pass path.isAbsolute (drive-relative), so the resolver treated the configured root as authoritative, searched only it, found nothing, and fell through to the generic install message. Automatic discovery (%APPDATA%\npm\node_modules\@deepseek-ai\dsh) was never consulted. Current builds reject such win32 values up front via drive-letter validation and keep the three path settings machine-scoped, so Settings Sync no longer ships them across devices.

Fix: remove dsh.local.packageRoot and dsh.local.nodePath from the affected machine's user settings (or set machine-correct values) and reload the window. Automatic discovery then finds the installed package and Node from PATH.

Planned hardening (recorded here, not yet implemented):

  • Clean restart (Restart-Clean): A-batch startup classification is complete; the clean-overlay restart flow for HEALTH_TIMEOUT / SPAWN_EXITED_EARLY is still planned.

License

MIT © Xizhi1024

上一个 Prev clat 下一个 Next dsh-tool-todo-tree
